Variable Width Undercarriage*
To enable passage through narrow spaces such as doorways and gates, the adjustable width track frame can be reduced by simply operating a single lever. Plus, changing the blade width is as easy as removing one pin by hand.
*Available on K008-3, K008-5, U10-5, KX018-4
Clean Running Kubota Tier 4 Engine
Kubota excavators are all powered by Kubota Tier 4 emission engines. The modern engine design maximizes digging and lifting performance, delivers minimized noise and vibration and meets the latest engine emission regulation.
Two Speed Travel
All Kubota excavators have a two speed drive that allows for efficient machine maneuverability and backfill operations.
Changeable Control Pattern
Convenient Two-pattern Selection System (TPSS) allows you to change between ISO and SAE operating patterns with a quick flip of the TPSS switch – without tools or leaving your seat.
|Engine Model||Engine ModelKubota D722-E4|
|Horsepower (gross)||Horsepower (gross)10.3|
|Displacement (cu. in.)||Displacement (cu. in.)43.8 (719)|
|Overall Length||Overall Length9ft 9in (2980)|
|Overall Height||Overall Height7ft 5in (2260)|
|Overall Width||Overall Width3ft 3in (990) / 2ft 6in (750)|
|Min. Ground Clearance||Min. Ground Clearance5.5in (140)|
|Crawler Length||Crawler Length4ft 5in (1340)|
|Pump Capacity (GPM)||Pump Capacity (GPM)2.8 (10.5) x 2|
|Auxiliary Hydraulics Flow Rate (GPM)||Auxiliary Hydraulics Flow Rate (GPM)5.5 (21.0)|
|Bucket Breakout Force (lbs.)||Bucket Breakout Force (lbs.)2337 (1060)|
|Arm Breakout Force (lbs.)||Arm Breakout Force (lbs.)1214 (550.6)|
|Traveling Speed: High (mph)||Traveling Speed: High (mph)2.5 (4.0)|
|Traveling Speed: Low (mph)||Traveling Speed: Low (mph)1.2 (2.0)|
|Ground Contact Pressure (psi)||Ground Contact Pressure (psi)4.2 (0.30)|
|Blade Width||Blade Width3ft 3in / 2ft 6in (990 / 750)|
|Blade Height||Blade Height7.9in (200)|
|Hydraulic Oil Reservoir / System||Hydraulic Oil Reservoir / System3.3 / 4.5 (12.6 / 17.1)|
|Fuel Reservoir||Fuel Reservoir3.2 (12.0)|
|Operating Weight lbs. (kg)||Operating Weight lbs. (kg)2646 (1200)|
